import processing.pdf.*;
boolean bRecordingPDF = false;

float inch = 72;
float diamArtInner = inch * 1.50;
float diamArtOuter = inch * 4.80;
float diamCutInner = inch * 1.41;
float diamCutOuter = inch * 4.875;
float holeDy = inch * 0.23;
float holeDx = inch * 0.20;
float holeD = inch * 0.1;

final int nFrames = 10;
int myFrameCount = 0;
int exportFrameCount = 0;
boolean bAnimate = true;
boolean bExportFrameImages = false;

//-------------------------------------------------------
void setup() {
  size(792, 612); // 11x8.5" at 72DPI
  frameRate(15);
  smooth();
}

//-------------------------------------------------------
void draw() {
  background(240);
  if (bRecordingPDF) {
    beginRecord(PDF, "praxinoscope-output.pdf");
  }

  // Do all the drawing.
  pushMatrix();
  translate(width/2, height/2);
  drawCutLines();
  drawGuides();
  drawAllFrames();
  popMatrix();

  if (bExportFrameImages) {
    // If activated, export .PNG frames
    if (exportFrameCount < nFrames) { String filename = "frame_" + nf((exportFrameCount%nFrames), 3) + ".png"; saveFrame("frames/" + filename); println("Saved: " + filename); exportFrameCount++; if (exportFrameCount >= nFrames) {
        bExportFrameImages = false;
        exportFrameCount = 0;
      }
    }
  }

  if (bRecordingPDF) {
    endRecord();
    bRecordingPDF = false;
  }
}


//-------------------------------------------------------
void keyPressed() {
  switch (key) {
  case ' ':
    // Press spacebar to pause/unpause the animation.
    bAnimate = !bAnimate;
    break;

  case 'p':
  case 'P':
    // Press 'p' to export a PDF for the Praxinoscope.
    bRecordingPDF = true;
    break;

  case 'f':
  case 'F':
    // Press 'f' to export .png Frames (to make an animated .GIF)
    myFrameCount = 0;
    exportFrameCount = 0;
    bExportFrameImages = true;
    bAnimate = true;
    break;
  }
}

//-------------------------------------------------------
void drawCutLines() {
  fill(0);
  textAlign(CENTER, BOTTOM);
  text("Praxinoscope Template", 0, 0-diamCutOuter/2-6);

  stroke(0);
  strokeWeight(1.0);

  noFill();
  if (!bRecordingPDF) {
    fill(255);
  }
  ellipse(0, 0, diamCutOuter, diamCutOuter);

  noFill();
  if (!bRecordingPDF) {
    fill(240);
  }
  ellipse(0, 0, diamCutInner, diamCutInner);

  noFill();
  ellipse(diamCutOuter/2 - holeDx, 0-holeDy, holeD, holeD);

  line (diamCutInner/2, 0, diamCutOuter/2, 0);
}

//-------------------------------------------------------
void drawGuides() {
  // This function draws the guidelines.
  // Don't draw these when we're exporting the PDF.
  if (!bRecordingPDF) {

    noFill();
    stroke(128);
    strokeWeight(0.2);
    ellipse(0, 0, diamArtInner, diamArtInner);
    ellipse(0, 0, diamArtOuter, diamArtOuter);

    for (int i=0; i<nFrames; i++) {
      float angle = map(i, 0, nFrames, 0, TWO_PI);
      float pxi = diamArtInner/2 * cos(angle);
      float pyi = diamArtInner/2 * sin(angle);
      float pxo = diamArtOuter/2 * cos(angle);
      float pyo = diamArtOuter/2 * sin(angle);
      stroke(128);
      strokeWeight(0.2);
      line (pxi, pyi, pxo, pyo);
    }

    // Draw the red wedge outline, highlighting the main view.
    int redWedge = 7; // assuming nFrames = 10
    for (int i=redWedge; i<=(redWedge+1); i++) {
      float angle = map(i, 0, nFrames, 0, TWO_PI);
      float pxi = diamArtInner/2 * cos(angle);
      float pyi = diamArtInner/2 * sin(angle);
      float pxo = diamArtOuter/2 * cos(angle);
      float pyo = diamArtOuter/2 * sin(angle);
      stroke(255, 0, 0);
      strokeWeight(2.0);
      line (pxi, pyi, pxo, pyo);
    }
    noFill();
    stroke(255, 0, 0);
    strokeWeight(2.0);
    float startAngle = redWedge*TWO_PI/nFrames;
    float endAngle = (redWedge+1)*TWO_PI/nFrames;
    arc(0, 0, diamArtInner, diamArtInner, startAngle, endAngle);
    arc(0, 0, diamArtOuter, diamArtOuter, startAngle, endAngle);


    for (int i=0; i<nFrames; i++) {
      float angle = map(i, 0, nFrames, 0, TWO_PI);

      pushMatrix();
      rotate(angle);
      float originY = ((diamArtOuter + diamArtInner)/2)/2;
      translate(0, 0-originY);

      noFill();
      stroke(128);
      strokeWeight(0.2);
      line (-inch/2, 0, inch/2, 0);
      line (0, -inch/2, 0, inch/2);

      popMatrix();
    }
  }
}

//-------------------------------------------------------
void drawAllFrames() {
  for (int i=0; i<nFrames; i++) {
    float angle = map(i, 0, nFrames, 0, TWO_PI);
    float originY = ((diamArtOuter + diamArtInner)/2)/2;

    pushMatrix();
    rotate(angle);
    translate(0, 0-originY);
    scale(0.8, 0.8); // feel free to ditch this

    int whichFrame = i;
    if (bAnimate) {
      whichFrame = (i+myFrameCount)%nFrames;
    }
    drawArtFrame (whichFrame);
    // drawArtFrameAlternate (whichFrame);

    popMatrix();
  }
  myFrameCount++;
}


//-------------------------------------------------------
void drawArtFrame (int whichFrame) {
  // Draw the artwork for a generic frame of the Praxinoscope,
  // given the framenumber (whichFrame) out of nFrames.
  // NOTE #1: The "origin" for the frame is in the center of the wedge.
  // NOTE #2: Remember that everything will appear upside-down!

  // Draw the frame number
  fill(0);
  noStroke();

  // Draw a pulsating ellipse
  noFill();
  stroke(0);
  strokeWeight(1);
  float t = map(whichFrame, 0, nFrames, 0, 1);
  float diam = map(cos(t*TWO_PI), -1, 1, 25, 50);
  ellipse(0, 0, diam, diam);

  //rotating circle
  float radius = diam/2;
  float rotatingArmAngle = (whichFrame*.1) * TWO_PI;
  float px = 0 + radius*cos(rotatingArmAngle);
  float py = 0 + radius*sin(rotatingArmAngle);
  fill    (0);
  stroke(51);
  ellipse(px, py, 8, 8);

  //rotating circle
  float rotatingArmAngle2 = (whichFrame*.1) * TWO_PI;
  float px2 = 15 + radius*cos(rotatingArmAngle2);
  float py2 = 15 + radius*sin(rotatingArmAngle2);
  fill    (0);
  stroke(51);
  ellipse(-px2, -py2, 8, 8);

  float px3 = -12 + radius*cos(rotatingArmAngle2);
  float py3 = -20 + radius*sin(rotatingArmAngle2);
  fill    (0);
  stroke(51);
  ellipse(-px3, -py3, 8, 8);

  //rect figure
  float amplitude=100;
  float f=.1;
  float xR=160;
  float yR=(160)+amplitude*sin(f*whichFrame);
  rect(xR,yR,10,10);
}
//-------------------------------------------------------
void drawArtFrameAlternate(int whichFrame) {
  // An alternate drawing test.
  // Draw a falling object.


  // Draw a little splat on the frame when it hits the ground.
  if (whichFrame == (nFrames-1)) {
    stroke(0, 0, 0);
    strokeWeight(0.5);
    int nL = 10;
    for (int i=0; i<nL; i++) {
      float a = HALF_PI + map(i, 0, nL-1, 0, TWO_PI);
      float cx = 12 * cos(a);
      float cy = 10 * sin(a);
      float dx = 16 * cos(a);
      float dy = 13 * sin(a);
      line (cx, 45+cy, dx, 45+dy);
    }
  }

  // Draw a little box frame
  fill(255);
  stroke(0, 0, 0);
  strokeWeight(1);
  rect(-5, -50, 10, 100);

  // Make the puck accelerate downward
  float t = map(whichFrame, 0, nFrames-1, 0, 1);
  float t2 = pow(t, 2.0);
  float rh = 8 + whichFrame * 0.5; // wee stretch
  float ry = map(t2, 0, 1, 0, 100-rh) - 50;

  noStroke();
  fill(0, 0, 0);
  rect(-5, ry, 10, rh);
}
