creatyde-AnimatedLoop

“Existence Ad Nauseam”

To come up with a concept was rather difficult, because I was thinking of how to best utilize the concept of endless time.  I then thought of the ideas of the nihilists, who believe there is no inherent meaning in anything.  That reality will continue on, complicated, writhing, and going and going.  Existence is ephemeral and imperfect; it comes up again and again, in a dogged loop.  Any kind of observer or life in reality is made from the infinitesimal pieces of the formless reality itself, the small white pieces coming from the noise.  Through a mixture of patterns and randomness, the pieces come together to form something of meaning, in this case the face of an observer.

I like the concept I finally went with.  However, I had originally wanted the contours to be more “worm-like,” to further suggest the materialistic, basic nature of life.  This caused problems when order was supposed to be achieved, so for the sake of simplicity, I allowed that idea to go.  I used the HannWindow function because it had a “bump” in the middle.  I used it to float the “writhing worms” to the center and then back to the periphery with a kind of easing in and easing out.

Here are some sketches of my thoughts during conceptualization:

// Using the template provided by Dr. Golan Levin
// Thanks to OpenCV made by Greg Borenstein
import gab.opencv.*;

//===================================================

// Global variables.
int nFramesInLoop = 100;
int nElapsedFrames;
boolean bRecording;

PImage img; // reference image for contours
PImage backs[]; // background image array
int numBack = 5; // number of background images
int backChange = 3; // duration of each background image
OpenCV opencv;
ArrayList contours;
ArrayList pos;
// variable to determine direction of general contour movement
boolean alt;

//===================================================

void setup() {

  size (600, 600);
  bRecording = false;
  nElapsedFrames = 0;
  stroke(255);
  fill(255);
  strokeWeight(1.3);

  // creating background images
  // https://forum.processing.org/two/discussion/13712/
  // how-to-add-noise-to-the-image-being-drawn
  backs = new PImage[numBack];
  for (int k = 0; k < numBack; k++) {
    background(200);
    loadPixels();
    for (int i = 0; i < width; i+=2) {
      for (int j = 0; j < height; j+=2) {
        float gray = 2*random(-1, 1);
        color c = 10*color(2*random(-1,1)+gray,
          2*random(-1,1)+gray, 2*random(-1,1)+gray);
        pixels[i+j*width] += c;
        pixels[i+(j+1)*width] += c;
        pixels[(i+1)+j*width] += c;
        pixels[(i+1)+(j+1)*width] += c;
      }
    }
    updatePixels();
    String name = "background" + k + ".jpg";
    save(name);
    backs[k] = loadImage(name);
  }

  // setup image
  img = loadImage("image.png");
  img.resize(250, 250);
  opencv = new OpenCV(this, img);
  contours = opencv.findContours();

  // setup contours
  pos = new ArrayList();
  int i = 0;
  for (Contour c : contours) {
    ArrayList arr = c.getPoints();
    pos.add(arr.get(0).copy());
    for (int k = 0; k < c.numPoints(); k++) {
       arr.get(k).x = arr.get(k).x - pos.get(i).x;
       arr.get(k).y = arr.get(k).y - pos.get(i).y;
    }
    i++;
  }
  // initialize direction of contours
  alt = false;
}

//===================================================

// Thanks to Dr. Golan Levin for Pattern-master
function float function_HannWindow (float x) {
  // http://en.wikipedia.org/wiki/Window_function
  float y = 0.5 * (1.0 - cos(TWO_PI*x));
  return y;
}

void draw() {

  // Compute a percentage (0...1) representing
  // where we are in the loop.
  float percentCompleteFraction = 0;
  if (bRecording) {
    percentCompleteFraction = (float) nElapsedFrames
      / (float)nFramesInLoop;
  }
  else {
    percentCompleteFraction = (float) (frameCount % nFramesInLoop)
      / (float)nFramesInLoop;
  }

  // Render the design, based on that percentage.
  renderMyDesign (percentCompleteFraction);

  // If we're recording the output, save the frame to a file.
  if (bRecording) {
    saveFrame("output/creatyde-loop-" + nf(nElapsedFrames, 4)

+ ".png");
    nElapsedFrames++;
    if (nElapsedFrames >= nFramesInLoop) {
      bRecording = false;
    }
  }
}

//===================================================

void renderMyDesign (float percent) {
  // pre-saved noise image
  image(backs[(frameCount/backChange)%numBack], 0, 0);
  if (frameCount % nFramesInLoop/2 == 0) {
    alt = !alt;
  }
  // draw contours of the face
  pushMatrix();
  translate(width/3.4, height/3.4); // true position
  int i = 0;
  float f = function_HannWindow(percent);
  float co = 1-sqrt(f);
  float t = 300*co; if (alt) t *= -1;
  float s = 1-abs(co);
  for (Contour c : contours) {
      pushMatrix();
      rotate(radians(360/contours.size()*i));
      translate(t, 0);
      rotate(-radians(360/contours.size()*i));
      translate(pos.get(i).x+random(-5,5),
        pos.get(i).y+random(-5,5));
      rotate(co);
      scale(s+random(-0.1,0.1));
      c.draw();
      popMatrix();
      i++;
  }
  popMatrix();
}

//===================================================

void keyPressed() {
  bRecording = true;
  nElapsedFrames = 0;
}
