Letters (OOP) will fall down from a random position and stops when it “collides” with an object.
The letters will also trace around an object’s edge through an algorithm that pushes the letter
upwards by checking the brightness of the vertical pixels above it.

Githun link: https://github.com/BlueSpiritbox/p1_textrain

import processing.video.*;

PFont f;

Capture video;
Letter[] letters;


int w = 640;
int h = 480;

String message = "For Part B of this assignment, you are asked to implement “Text Rain” in Processing. Reimplementing a project like this can be highly instructive, and test the limits of your attention to detail.";


color thresholdColor;


void setup() {
  size(w, h);  //window size

  f = createFont("Arial", 16, true);
  textFont(f);

  letters = new Letter[message.length()];
  for( int i = 0; i < message.length(); i++ ) {
    letters[i] = new Letter( random(0,width), 0, message.charAt(i) );
  }

  //Checks which cameras are available
  //  String[] cameras = Capture.list();
  //  if (cameras.length == 0) {
  //    println("There are no cameras available for capture.");
  //    exit();
  //  } else {
  //    println("Available cameras:");
  //    for (int i = 0; i < cameras.length; i++) {
  //      println(cameras[i]);
  //    }
  //  }

  video = new Capture(this, w, h, 30); //initiates capture
  video.start();  //starts capturing video

  smooth();
}

void draw() {
  if ( video.available() ) {
    video.read();  //reads video input
  }

  image(video, 0, 0);  //displays video image

  for( int i = 0; i < message.length(); i++ ) {
    letters[i].update();
    letters[i].display();
  }
}


class Letter {

  char letter;
  float x, y;
  int velocity;
  int brightnessThreshold = 150;

  long start;
  long delay;
  float life = 255;
  boolean dying = false;

  Letter( float _x, float _y, char _letter ) {  //creates Letter instance
    x = _x;
    y = _y;
    letter = _letter;
    velocity = round(random(1,3));
    life = round(random(100,256));

    start = millis();
    delay = round(random(500,10000));  //delay when letter falls at the beginning
  }

  void display() {  //displays Letter
    fill(100, life);
    text(letter, x, y);
  }

  void update() {  //update letter variables

    if( y >= height ) {  //reset if letter at the bottom
      x = random(0,width);  //give random x position
      y = 0;

    } else {
      if( brightness(video.pixels[round(x+y*width)]) < brightnessThreshold ) {  //if letter position is dark, stop letter

        //algorithm to push letter up to follow the "edge"
        if( y > 0 && y != 0) {  //only push up if y pos is not at 0
          float _y = y;  //temp y

          for( int i = int(y); i > 0; i-- ) {  //look at every single pixel above letter
            if( brightness(video.pixels[round(x+i*width)]) > brightnessThreshold ) {  //if it is bright
              _y = i;  //make that new y position
              break;  //stop looking for next pixel
            }
          }
          y = _y;  //update y position
        }
      } else {  //move letter down
        if ( (millis() - start) > delay) {  //delay
          y += 1;
        }
      }
    }
  }

}

GitHub: https://github.com/andybiar/TextRain

import processing.video.*;

Capture cam;
PFont f;
PImage bg;
final int WIDTH = 640;
final int DARK_THRESHOLD = 120;
Letter[] fallers;
Letter[] droppers;
int dropCount = 0;
final String[] WORDS = {"H","i","m","y","n","a","m","e",
"i","s","A","n","d","y","B","i",
"a","r","a","d","I","l","i","k",
"e","t","o","m","a","k","e","t",
"h","i","n","g","s","f","o","r",
"p","e","o","p","l","e","t","o",
"d","i","s","c","o","v","e","r",
"w","i","t","h","f","u","n","!"};

void setup() {
size(WIDTH, 480);

String[] cameras = Capture.list();
if (cameras.length == 0) println("No cameras");
else cam = new Capture(TextRain.this, cameras[0]);
cam.start();

f = createFont("Verdana", 18, true);
textFont(f);
fill(10);

fallers = new Letter[WIDTH/10];
droppers = new Letter[WIDTH/10];
}

int nextDrop() {
if (dropCount >= WIDTH/10) return -1;

int rand = int(random(WIDTH/10));
while(fallers[rand] != null) {
rand = (rand + 1) % (WIDTH/10);
}

return rand;
}

void draw() {
// Get background from webcam
if (cam.available() == true) cam.read();
image(cam, 0, 0);
loadPixels();

// Drop a letter
if (dropCount < 64 && (millis() / 1000) > dropCount) {
int nextDrop = nextDrop();
if (nextDrop != -1) {
fallers[nextDrop] = new Letter(WORDS[nextDrop%WORDS.length],
nextDrop*10, 0);
}
dropCount++;
}

// Draw letters
for (int i = 0; i < fallers.length; i++) {
Letter n = fallers[i];
if (n != null) text(n.letter, n.x, n.y);
}

// Gravity
for (int i = 0; i < fallers.length; i++) {
if (fallers[i] != null) {
Letter a = fallers[i];
if (a.y >= height || a.y < 0) continue;
color c = pixels[WIDTH * a.y + a.x];
float r, g, b;
r = red(c); g = green(c); b = blue(c);
int brightness = int(.2989*r + .5870*g + .1140*b);
if (brightness > DARK_THRESHOLD) fallers[i].y += 1;
}
}

// Reset falling letters
for(int i = 0; i < fallers.length; i++) {
if (fallers[i] != null && fallers[i].y >= height) {
fallers[i].y = 0;
}
}
}

public class Letter {
public String letter;
public int x;
public int y;

public Letter(String letter, int x, int y) {
this.letter = letter;
this.x = x;
this.y = y;
}
}

I think Text Rain is one of my weaker projects in the upkit intensive, but here it is. I used an object-oriented approach, creating a Letter class which stored it’s x and y position as well as the character to be drawn. Other than that, my implementation is likely pretty vanilla – I used the Capture object to get pixels from the webcam, loaded them into an array, and read points under the letters for darkness above a certain threshold. Definitely a fun starter project! Also, this is the first time in my life I have ever intentionally not shaved my stache, and I think it looks pretty good in this photo:

TextRain_Processing from kaikai on Vimeo.

This was a very fun project for me. It’s the first processing sketch I wrote from scratch that does some relatively more complex things other then just drawing.
